Arctic Alpine 23 CPU Cooler for AMD Sockets AM5 / AM4

Future-Proof Compatibility
Because all mechanical dimensions remain identical to the AM4, we can guarantee the compatibility of ARCTIC coolers with AMD's AM5 and AM4 processors.

Improved Cooling Performance by New Production Process
The high thermal conductivity of aluminum is fully retained by a new type of extrusion. This new production process creates a powerful yet very compact radial heat sink. The particularly thin cooling fins of the new Alpine are fanned out in a Y-shape. This increases the surface area of the heat sink and therefore the cooling capacity.

Wide rpm Range
The Alpine 23 features a new motor technology with a very wide, PWM-controlled rpm range. This keeps the noise level at a minimum while guaranteeing maximum cooling performance when needed.

High-Quality Bearing
Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan.

Extended Life Span
A 10°C lower motor temperature roughly doubles the life span of a fan. The new ARCTIC motor has a four times longer service life through its low coil temperature.

Pre-Applied MX-2 Thermal Paste
The pre-applied, high-performance MX-2 thermal compound ensures fast and clean installation.

Easy and Fast Installation
Thanks to the mounting clips, the installation is really easy. Alpine 23 is simply plugged into the existing AMD retention modules and screwed tight.

• Compatibility

  • AMD Socket: AM5, AM4
  • Operating Ambient Temperature: 0 - 40 °C
• Heatsink
  • Outer Diameter: 93.4 mm
  • Fin Material: Aluminum
  • Number of Fins: 50 Y-shaped Fins
  • Thermal Paste: MX-2 pre-applied
• Fan
  • Fan Diameter: 90 mm
  • Fan Speed: 100 - 2000 rpm
  • Fan Bearing: Fluid Dynamic Bearing
  • Noise Level: 0.3 Sone
  • Current: 0.06 A
  • Connector: 4-Pin
• Size & Weight
  • Installation height: 65 mm
  • Length: 98.6 mm
  • Width: 121 mm
  • Height: 65 mm
  • Weight: 275.5
