Epson TM-T20IV (102) Thermal 80mm Receipt Printer (USB - Serial - Ethernet)
Download Software (Epson Website)
Please note that a USB cable is not included with the printer. If you require a USB cable, check:
Epson POS receipt printer (C31CL47102)
Triple Interface (USB + Serial + Ethernet) | 250mm/s High-Speed | 203 dpi
The Epson TM-T20IV (102) is an industrial-grade thermal printer engineered for maximum deployment flexibility. By including USB, Serial, and Ethernet interfaces as standard, the (102) model serves as a "future-proof" investment, allowing you to switch from a local serial or USB connection to a networked Ethernet environment at any time without hardware modifications.
Technical Specifications
- Connectivity: Triple Interface - USB + RS-232 Serial + Ethernet
- Print Speed: Max 250 mm/sec
- Resolution: 203 dpi x 203 dpi
- Auto-Cutter: Rated for 2 Million Cuts
- Reliability: 60 Million Lines (MCBF) / 360,000 Hours (MTBF)
- Paper Width: 80mm standard (58mm with included spacer)
Highlights
-
Universal Compatibility: Supports traditional PC-POS via Serial/USB and modern mPOS/Cloud systems via Ethernet.
-
Modern, Compact Design: Occupies a smaller footprint than previous generations, making it ideal for cramped retail or hospitality counters.
-
Eco-Conscious Features: Integrated paper-saving functions can reduce paper consumption by up to 30% by narrowing top/bottom margins and reducing character height.
-
Status Monitoring: Features an intuitive LED display for at-a-glance troubleshooting of paper levels or connectivity issues.
General |
|
| Product dimensions (WxDxH) | 140‎ x 199 x 146 mm |
| Product weight | 1.7 kg |
| Colour | Black (EBCK) |
| Noise Level | Operation (Roll): 55 dB (A) |
| Supported Humidity |
|
| Supported Temperature |
|
| Interfaces |
|
| Data Buffer | 4 kB or 128 Bytes |
Reliability |
|
| Reliability |
|
| Auto Cutter Life | 2.000.000 Cuts |
| Printer Life | 15.000.000 Lines |
| Print Head Life | 150 km - 150.000.000 pulses |
Print type |
|
| Print method | Thermal line printing |
| Technology | Thermal Line |
Fonts & Styles |
|
| Print Speed |
|
| Printing Font Receipt | ANK |
| Column capacity receipt | Paper width 80 mm, 48 / 64 |
| Character set receipt |
|
| Characters per inch | 22.6 cpi / 16.9 cpi |
| Dot density | 203 DPI x 203 DPI |
| Colour Printing | Black |
Paper |
|
| Paper Types | Receipt |
| Paper size roll paper |
|
Power |
|
| Power Supply | AC adapter (C1) |
| Power Consumption |
|
| Operating Voltage | 24 V |
Standards Compliance |
|
| EMC Standards |
|
| Safety standards |
|
Other Features |
|
| Cutter | Partial Cut |
| Sensors |
|
| Paper Saving Function | Yes |
What's in the box |
|
| Main Unit | TM-T20IV printer |
| AC Adapter (C1) | 24V power brick |
| AC Cable | Euro power cord |
| Cable Cover | A plastic snap-on piece to hide and protect the rear connections |
| Paper Roll Spacer | A plastic guide used only if you want to switch from 80mm to 58mm paper rolls |
| Power Switch Cover | A transparent flip-guard to prevent accidental power-offs |
| Wall Hanging Bracket | Mounting hardware for vertical installation |
| Starter Paper Roll | A small test roll for initial setup |
| Colour | Black |
|---|---|
| Printing | Monochrome |
| Media | Receipt |
| Technology | Direct Thermal |
| Type | |
| Interface | Ethernet, Serial, USB 2.0 |
