Pro'sKit SS-553 Industrial Solder Pot

250W | Lead-Free Titanium Plated | 1.6kg Capacity

The Pro'sKit SS-553B is a high-capacity, temperature-controlled soldering bath designed for professional electronic manufacturing and wire harness processing. Engineered for Lead-Free (Pb-Free) compatibility, it features a heavy-duty titanium-plated crucible that resists corrosion from high-temperature alloys.

Technical Specifications

• Model: SS-553B
• Voltage: 220V - 240V AC
• Power Consumption: 250 Watts
• Temperature Range: 100°C – 450°C
• Crucible Material: Stainless Steel with Titanium Plating
• Crucible Size (Inner): Ø 80mm x 40mm (Depth)
• Solder Capacity: Approx. 1600g (1.6kg)
• Melting Time: ~10 to 20 Minutes (Approximate)
• Unit Dimensions: 210mm x 140mm x 65mm

Model-Specific Engineering Features

• Advanced Heating Architecture: Utilises an iron-chromium-aluminium wire heater paired with an aluminosilicate heat-preservation material for superior thermal stability and rapid heat recovery.

• High-Grade Titanium Plating: The crucible's titanium finish provides a non-stick surface that reduces tin oxide buildup and resists acid/corrosion, essential for long-term lead-free operation.

• Microprocessor Control: Designed with an electronic control board that provides precise temperature adjustment via a rotary dial, ensuring the bath stays within +/-5°C of your set point.

• Ceramic Insulation: Features a ceramic heater insulated tube, providing an extra layer of protection against high-temperature operation and improving electrical safety.

Common Applications

• Wire Harness Manufacturing: Rapid tinning of stripped wire ends for automotive and industrial looms.

• Component Salvage: Desoldering multi-pin components from legacy boards.

• Coil & Transformer Winding: Stripping and tinning of enamelled copper wire in a single dip.

• Dross Cleaning: Reclaiming solder or maintaining small-scale wave soldering tools.

Technical Usage Tip: To maximize the lifespan of the titanium plating, always keep the pot at least half-full of solder when powered on. Dry-firing the pot can cause localized hotspots that may degrade the crucible surface. Always use in a well-ventilated area or under a fume extractor.
