Digitus 24 Port CAT6a Shielded 1U 19-inch Rackmount Patch Panel

The DIGITUS "DN-91624S-EA" CAT 6A Patch Panel is available as 24-port version and is made of 1.5 mm cold-rolled steel which makes it a sturdy Patch Panel for 19" rack mounting.

It complies with the 802.3at PoE+ and the 802.3af PoE standardand is equipped with dust protection shutters.

• Sturdy patch panel with metal housing
• Complete shielding of housing and shield contact
• Cable installation by IDC-strips
• Central grounding connector
• Dielectric strength up to 1500 VDC (contact/ground)
• Metal-coated (electrically conductive) cable fixation for grounding the cable shield

• Transmission properties: Category 6A, Class EA
• Area of application: Up to 500 MHz, 10GBase-T
• Norms: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C, 802.3af, 802.3at PoE+
• General properties:
  • Suitable for 483 mm (19") cabinet mounting
  • RJ45 female, 8P8C
  • Cable installation via LSA strips, colour-coded according to EIA/TIA 568 A & B
  • Cable fixing with smart cable ties
  • Central ground connection
  • 360° shield coverage
• Mechanical properties:
  • Housing material: 1.5 mm galvanic cold rolled steel, acc. to EN1.4301, UNS S30400, AISI 304 and LMSAD110
  • RJ45 female material: ABS UL 94V-0
  • RJ45 female contact: Tinned phosphor bronze, 0.5 μ gold-plated contact
  • RJ45 shielding: Tinned bronze
  • LSA termination clamp: Krone LSA+, UL 94V-0, zinc plated phosphor bronze
  • Ground wire: Not included
  • Conductor plate: FR4, UL 94V-0
• Physical properties:
  • Insertion force: 30N max. (IEC 60603-7-5)
  • Retention strength: 7.7 kg between jack and plug
  • Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
  • Mating cycles female: > 750 acc. to ISO/IEC 11801, IEC 60603-7-5
  • Clamp: > 200 acc. to ISO/IEC 11801, IEC 60603-7-5
  • Insulation resistance: > 500 MOhm
  • Contact resistance: < 20 MilliOhm
  • Dielectric strength: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Ground)
  • Ports: 24
  • Category: CAT 6A
