Digitus CAT7 S-FTP (LS0H - Cca) Network Installation Cable (per meter)

Description

The Digitus Professional Cat.7 S/FTP installation cable is characterized by the following cable construction 4x2x AWG23/1 and reaches a transmission frequency up to 1200 MHz. The halogen-free cable jacket conforms to the standard IEC 60332-3-24, FRNC-C, LSZH-3 and CPR Euro class Cca. The cable is suitable for building structured cabling in the secondary and tertiary areas. Compliant with the following standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-4-1.

Future-oriented standards and high-end quality for your network.

• 10GBit Ethernet
• 1200 MHz transmission frequency
• Permanent link certified
• PoE Power over Ethernet support
• CPR class Cca

Technical details

• Physical properties:

• Conductor: Bare annealed copper, solid AWG 23/1
• Insulation: SFS-PE (Foam-Skin Polyethylene)
• Total number of insulated conductors: 8, twisted in 4 pairs
• Color code: Blue-white, orange-white, green-white, brown-white
• Individual pair shielding: Aluminum foil, providing 100 % coverage
• Overall shielding: Copper braid
• Outer sheath: Eca to B2ca acc. to EN 50575; LSZH
• Outer sheath diameter (nominal): 0,50 mm (Eca); 0,52 mm (Dca); 0,60 mm (Cca); 0,60 (B2ca)
• Colour: Orange (RAL 2000)

• Mechanical properties:

• Tensile loading: 150N max.
• Dynamic bending radius: 8x AD mm min.
• Static bending radius: 4x AD mm min.
• Shipping- and storage temperature range: -20 °C up to +75 °C
• Operating temperature range: -20 °C up to +50 °C
• Installation temperature range: 0 °C up to +50 °C
• Overall diameter Simplex (nominal): 7,0 mm (Eca); 7,2 mm (Dca); 7,5 mm (Cca); 7,5 mm (B2ca)
• Weight (kg/km): 49,5 kg (Eca); 51 kg (Dca), 53 kg (Cca); 53 kg (B2ca)

• Electrical properties:

• Impedance: 100±15 Ohm @ 4 - 1000 MHz; 100±25 OHM @ 100-600 MHz
• Capacitance: 45 pF/m nominal @ 1 KHz
• Capacitance unbalance (pair-ground): 1.6 pF/m max. @ 1 KHz
• Insulation resistance: 5 GOhm x km min.
• DC resistance: 95 Ohm/km max. (2% max. resistance unbalance)
• DC loop resistance: 190 Ohm/km max. (2% max. resistance unbalance)
• Voltage resistance: 72 Vdc max.
• Coupling attenuation: CA-Type 1b
• Signal propagation delay: 450 nS/100 m max.
• Propagation delay: 10 nS/100 m max.
• Separating class: “d” acc. to EN 50174-2
• NVP: 79%
• Assortment: Twisted Pair Installation Cables
• Category: CAT 7
• Shielding: S-FTP, pairs in metal foil and braid shielding
• CPR: Cca
• Colour: orange
• Jacket: LSOH
• Structure: 4 x 2 AWG 23/1, solid twisted pair
