Digitus DS-43309 4K HDMI Video Wall Controller / Processor

DESCRIPTION

With the DIGITUS Video Wall Controller 2x2, you can transform a total of 4 TV sets or monitors with HDMI into a large-format video wall. The controller enables you to distribute a high-resolution 4K signal across 4 Full HD displays to create a large image. You can be as creative as you like: set up a classic 2x2 monitor wall or arrange 2 to 4 monitors horizontally or vertically, combining them to make a video wall.

By pressing a button on the device or the remote control included in delivery, you can switch between the different modes. The device also contains a splitter function that allows you to display the same image on all the monitors. With this professional tool, you are ideally equipped to display visualizations of all kinds for trade fairs, advertising or shop windows with a high degree of flexibility.

• Combine up to 4 displays into a video wall of your choice
• Ideal for all kinds of visualizations for display windows, trade fairs or advertising
• Supports various display formations (horizontal, vertical or combined)
• On Screen Display (OSD) for mode and port display

TECHNICAL DETAILS

• Resolution HDMI Input: 1 x 4K / 60 Hz (3840 x 2160p / YUV 4:4:4)
• Resolution HDMI Outputs: 4 x Full HD / 60 Hz (1920 x 1080p)
• Total bandwidth HDMI: 18 Gbps (all channels)
• Additional input resolutions supported: 480i, 480p,576p,576i,720p,1080i, 1080p (50/60Hz), 4K@24/25/30Hz, 4k@50/60Hz
• Supports display formations: 2x2, 1x2, 2x1, 1x3, 3x1, 1x4, 4x1 (vertical x horizontal)
• Supports display splitter mode: 1x4
• Operating temperature: 0°C ~ 70°C
• Operating humidity: 5% - 90% RH (non-condensing)
• Power supply power adapter: 100 - 240 V AC / 0.65 A
• Power supply device: 12 V / 2 A
• Length of mains cable: ca. 1.2 m
• Case material: Metal
• Dimensions: W 11.5 x D 11.1 x H 2.7 cm
• Weight: 395 g

PACKAGE CONTENT

• 1 x 4K HDMI® Video Wall Controller, 2 x 2
• 1 x Power adapter
• 1 x Remote control
• 1 x User manual
