DIGITUS Professional AC Fan for Cabinets

Description

The individual ventilator from DIGITUS serves as replacements to exchange with existing ventilator units from DIGITUS for network and server cabinets. Alternatively, the ventilator can also be individually wired and commissioned. For example, it can serve as an extension to the DIGITUS wall mounting cabinets for outdoor areas in which it can simply be snapped in on the inside in front of the existing filter.

• Serves as replacement ventilator for ventilator units from DIGITUS
• Can alternatively be commissioned as an individual ventilator

Technical details

• Dimensions: 120 x 120 x 38 mm
• Weight: 530 g
• 1-phase
• Power supply: 230 VAC
• Frequency: 50/60 Hz
• Power output: 0.14/0.12 A
• Power input: 22/21 W
• Speed: 2700/3100 RPM
• Air circulation: 161.40 / 195.38 m³/h
• Noise level: 42/47 dbA
• Operating temperature: -30 °C to +75 °C
• Life cycle: 50000 h
• Housing material: Die-cast aluminium alloy
• Caster material: UL 94-0 plastic
• Motor protection: Impedance protected
• Ball bearing
• Connection cable: Lead wires
• Colour: black, RAL 9005
• Filter: no

Package content

• 1 x Ventilator
