Aten VE812R HDMI HDBaseT Receiver for Single Cable Extender

Aten VE812R HDMI HDBaseT Receiver for Single Cable Extender

Name: Aten VE812R HDMI HDBaseT Receiver for Single Cable Extender
Brand: ATEN
SKU: 210012
Price: 162.155601 EUR
Availability: InStock

In stock

Only 1 left

SKU

210012

Be the first to review this product

Special Price €162.16 Regular Price €324.30

ATEN

The Aten VE812R HDMI Over Single Cat 5 Receiver supports HDBaseT technology that uses a single Cat 5e cable to extend signals up to 100m. The VE812R not only supports HDMI (3D, Deep Color) but also Ultra HD (4k) and is HDCP compatible. Furthermore remote EDID pass-through ensures optimum video quality for your HDMI display.

The VE812 is perfect for the meeting room, home theater or any installation that needs long distance transmission and superior video quality.

Implements HDBaseT extension technology using only one Cat 5e cable to connect the transmitter and receiver
HDMI (3D, Deep Color, 4k)
HDCP Compatible
Anti-jamming - resists signal interference during high-quality video transmission using HDBaseT technology
Long distance transmission - up to 100m
EDID Expert - selects the optimum EDID settings for smooth power-up and highest quality display
Supports up to 340MHz bandwidth for high performance video
Supports Dolby True HD and DTS HD Master Audio
Built-in 8KV / 15KV ESD protection (Contact voltage 8KV - Air voltage 15 KV)

Output Interface	1x HDMI Type A Female (Black)
Output Impedance	100 ohms
Max. Data Rate	10.2 Gbps (3.4 Gbps Per Lane)
Max. Pixel Clock	Up to 340 MHz
Compliance	HDMI (3D, Deep Color, 4K) HDCP Compatible Consumer Electronics Control (CEC)
Max. Resolutions / Distance	Up to 4K @ 70m (Cat 5e/6) Up to 4K @ 100m (Cat 6a) 1080p @ 100m 4K supported: 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0) 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
