Digitus CAT6 U-UTP Network Installation Cable (305m)
The Digitus® Professional Cat.6 U/UTP installation cable is characterized by the following cable construction:
-
Category 6 cables are made of 4 of high-performance twisted pair conductors, with higher specifications for lower cross talk and system noise than Cat5e cables. The cable standard provides performance of up to 250MHz and is used for Ethernet networks running at speeds up to 1 Gigabit. Cat6 cables are backward compatible with Cat5e systems.
-
U-UTP: Unshielded Unshielded Twisted Pair – U-UTP cables consist of pairs of wires twisted together with no electrical shielding. This is one of the most basic methods used to help prevent electromagnetic interference.
- Halogen free cable jacket conforms to the standard IEC 60332-1, FRNC-B, LSZH-1 and CPR Euro class Eca.
- It is suitable for building structured cabling in the secondary and tertiary area.
- Compliant with the following standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-6-1.
- PoE Power over Ethernet support
| Physical properties | Basic conductor | Solid AWG 23/1, bare annealed copper 0.57 mm nominal |
| Insulation | HD-PE | |
| Total number of insulated conductors | 8, twisted in 4 pairs | |
| Color code | Blue-white, orange-white, green-white, brown-white | |
| Individual pair shielding | None | |
| Overall shielding | None | |
| Outer jacket | Halogen-free (FRNC-B/LSZH-1) | |
| Outer jacket diameter | 0.5mm nominal | |
| Color | Purple (RAL 4005) | |
| Mechanical properties | Tensile loading | 150N max. |
| Dynamic bending radius | 8x AD mm min. | |
| Static bending radius | 4x AD mm min. | |
| Shipping- and storage temperature range | -20 °C up to +60 °C | |
| Operating temperature range | -20 °C up to +75 °C | |
| Installation temperature range | 0 °C up to +50 °C | |
| Overall diameter | 6.2 mm nom. | |
| Fire load | 320Mj/km | |
| Electrical properties | Mean impedance | 100±5 Ohm @ 1-600 MHz |
| Capacitance | 48 pF/m nominal @ 1 KHz | |
| Capacitance unbalance (pair-ground) | 1.5 pF/m max. @ 1 KHz | |
| Insulation resistance | 5 GOhm x km min | |
| Caloric value | 650MJ/m | |
| DC loop resistance | 147 Ohm/km max. (2% max. resistance unbalance) | |
| Voltage resistance | 72 Vdc max. | |
| Coupling attenuation | 40 dB | |
| Signal propagation delay | 535 nS/100 m max. | |
| Delay difference | 20 nS/100 m max. | |
| Separating class | “d” acc. to EN 50174-2 | |
| NVP | 79% | |
| Conductor material | Cu, bare | |
| Diameter conductor | 0.55 mm | |
| Nominal cross section conductor | 0.2582 mm² | |
| AWG-size | 23 | |
| Conductor category | Class 1 = solid | |
| Number of cores | 1 | |
| Stranding element | Pairs | |
| Core insulation | PE (polyethylene) | |
| Core identification | Colour | |
| Halogen free & smoke-proof | IEC 60754-2 & IEC 61034 | |
| Flame retardant | IEC 60332-1 | |
| Low smoke (acc. EN 61034-2) | Yes | |
| Category | 6 | |
| NVP value | 69% |
| Colour | Purple |
|---|---|
| Type | CAT 6 |
| Length | 305 m |
| Shielding | U-UTP |
| Conductor | Bare Copper |
| Outdoor | No |
