Digitus CAT6 U-UTP Network Installation Cable (per meter) DK-1613-VH-305 4016032324553

Digitus CAT6 U-UTP Network Installation Cable (per meter)

Name: Digitus CAT6 U-UTP Network Installation Cable (per meter)
Brand: DIGITUS
SKU: 370041-m
Price: 0.861401 EUR
Availability: InStock

In stock

SKU

370041-m

Be the first to review this product

€0.86

The Digitus® Professional Cat.6 U/UTP installation cable is characterized by the following cable construction:

Category 6 cables are made of 4 of high-performance twisted pair conductors, with higher specifications for lower cross talk and system noise than Cat5e cables. The cable standard provides performance of up to 250MHz and is used for Ethernet networks running at speeds up to 1 Gigabit. Cat6 cables are backward compatible with Cat5e systems.
U-UTP: Unshielded Unshielded Twisted Pair – U-UTP cables consist of pairs of wires twisted together with no electrical shielding. This is one of the most basic methods used to help prevent electromagnetic interference.
Halogen free cable jacket conforms to the standard IEC 60332-1, FRNC-B, LSZH-1 and CPR Euro class Eca.
It is suitable for building structured cabling in the secondary and tertiary area.
Compliant with the following standards ISO/IEC 11801, DIN EN 50173, DIN EN 50288-6-1.
PoE Power over Ethernet support

This cable is sold per meter.

Physical properties	Basic conductor	Solid AWG 23/1, bare annealed copper 0.57 mm nominal
	Insulation	HD-PE
	Total number of insulated conductors	8, twisted in 4 pairs
	Color code	Blue-white, orange-white, green-white, brown-white
	Individual pair shielding	None
	Overall shielding	None
	Outer jacket	Halogen-free (FRNC-B/LSZH-1)
	Outer jacket diameter	0.5mm nominal
	Color	Purple (RAL 4005)
Mechanical properties	Tensile loading	150N max.
	Dynamic bending radius	8x AD mm min.
	Static bending radius	4x AD mm min.
	Shipping- and storage temperature range	-20 °C up to +60 °C
	Operating temperature range	-20 °C up to +75 °C
	Installation temperature range	0 °C up to +50 °C
	Overall diameter	6.2 mm nom.
	Fire load	320Mj/km
Electrical properties	Mean impedance	100±5 Ohm @ 1-600 MHz
	Capacitance	48 pF/m nominal @ 1 KHz
	Capacitance unbalance (pair-ground)	1.5 pF/m max. @ 1 KHz
	Insulation resistance	5 GOhm x km min
	Caloric value	650MJ/m
	DC loop resistance	147 Ohm/km max. (2% max. resistance unbalance)
	Voltage resistance	72 Vdc max.
	Coupling attenuation	40 dB
	Signal propagation delay	535 nS/100 m max.
	Delay difference	20 nS/100 m max.
	Separating class	“d” acc. to EN 50174-2
	NVP	79%
	Conductor material	Cu, bare
	Diameter conductor	0.55 mm
	Nominal cross section conductor	0.2582 mm²
	AWG-size	23
	Conductor category	Class 1 = solid
	Number of cores	1
	Stranding element	Pairs
	Core insulation	PE (polyethylene)
	Core identification	Colour
	Halogen free & smoke-proof	IEC 60754-2 & IEC 61034
	Flame retardant	IEC 60332-1
	Low smoke (acc. EN 61034-2)	Yes
	Category	6
	NVP value	69%
